GSM 1/4 Wave stub antenna SMA-Male connector FPST35254-SM-ST

The PST2100 is a 1/4 wave stub antenna operating from 824-960 MHz and 1710-2170 MHz in the cellular bands. Housed in black sheath, the PST2100 is ideal for fixed and portable cellular terminals requiring a SMA mounted antenna.

 Radiating element - 1/4 Wave Element
 Frequency range -  824-960/1710-2170 MHz
 Gain -  0 dBi
 Polarisation -  Linear
 VSWR -  < 2.5:1
 Power rating - 10W
 Connector - SMA-Male Straight
 Dimensions - 76 x 8mm (plus connector)
